Beaumont, TX Plant: Progress Update

Our newest facility is strategically located and further ensures reliable supply through redundant manufacturing capabilities.

Phase 1

  • Scope: Purchase land & establish a rail distribution terminal
  • Status: Complete and operational



Phase 2

  • Scope: Infrastructure development for NGL processing facility
  • Status: In progress
  • Expected completion: Q4 2023

Phase 3

  • Scope: NGL processing
  • Status: In progress
  • Expected completion:
    • Commissioning of processing systems to begin Q1 2024.
    • Full-scale product online by Q2 2024.

Infrastructure Development for NGL Processing Facility

Scheduled for completion in Q4 2023

Scope includes:
  • Site preparation (civil).
  • Installation of a large-scale facility fire protection system designed to supply 11,000 gpm of fire water supplied from a six (6) million-gallon on-site reservoir.
  • Utilities:  Electrical, water, internet, and combustible gas detection systems.
  • Installation of overhead pipe racks and bridges to support bulk storage and processing areas.
  • Pilings and concrete foundations for processing equipment in the process areas.
  • Bulk storage for raw materials and processed products.  Six (6) 90,000-gallon tanks for R290 (propane) refrigerant production and five (5) 40,000-gallon tanks for R601a (isopentane) refrigerant production and Y-grade NGL products.
  • Process facility buildings including motor control center (MCC), operator process control room, and plant laboratory.

NGL Processing

Commissioning of processing systems to begin Q1 2024 | Full-scale product online by Q2 2024
Scope includes:
  • Design and installation of all necessary NGL processing equipment to produce high-purity NGL refrigerants including R290, R601a, and other light hydrocarbon refrigerant products to serve our Gulf Coast LNG customer base.
  • This phase includes a large scale 2-tower high purity NGL fractionation system, process heater, molecular sieve processing towers, and mercury removal units (MRUs).
parallax

Insulating Molecular Sieve Processing Towers

Installation of Vertical Turbine Fire Pumps

6M Gallon Fire Water Reservoir

Mercury Removal Unit (MRU) Vessels

Truck Scale for Transport Loading

90K Gallon Bulk Storage Tanks

6 tanks installed

40K Gallon Bulk Storage Tanks

5 tanks installed; space available for several more

Insulation of Refrigerated Ethane/Propane Mix Process Vessel

Fire Proofing of Vertical Storage Tank Support Skirts

Fire Water Monitor Cannon

Fire Pump House

Fire Water Pumps with Diesel Engines

3 pumps installed

Process Heater Installation

Deluge Piping Installation on Vertical Tanks

Tower 2 Overhead Condenser

Hot Oil Tank in place

Insulation applied to Fractionation Tower prior to erecting
